Model | Mirano Pellet PRO 24 |
Putere maxima/minima | 24,28 / 9,39 |
Putere termisa emisa in incaperea de amplasare max / min | 3 / 1 |
Consum mediu de peleti | 3,7 |
Randament (nominal / redus) | 93 / 94 % |
Temperatura max / min a gazelor de ardere | 102 / 73 °C |
Continut CO în gazele de ardere la 13% O | 92 mg/Nm³ |
Tiraj minim necesar | 12 Pa |
Conducta gaze arse | 80 Ø mm |
Conducta aer proaspat | 60 Ø mm |
Consum electric min/max | 60 / 310 |
Alimentare curent electric | 230 / 50 V/Hz |
Distante minime de siguranta | Spate 800 / Lateral 800 / Fata 1000 mm |
Tip combustibil | Peleti din lemn Ø6 - Ø8 |
Capacitate vas expansiune | 8 litri |
Racord Tur (filet exterior) | 1" |
Racord Retur (filet interior) | 1" |
Functionare la temp. mediu înconjurator | 5 - 40 °C |
Temperatura maxima a apei | 90 °C |
Umiditate la 30 ºC a mediului înconjurator | 85% |
Volum apa termoșemineu | 41 litri |
Presiune recomandata de lucru | 2 bar |
Inaltime H (max) | 1130 mm |
Latime W (max) | 585 mm |
Adancime D (max) | 615 mm |
Volum buncar | 39 kg |
Greutate | 170 kg |
Volum maxim de încalzit | pana la 680 m³ |
Putere termica (kW): 24 Kw
Gama puterii termice (kW): 10 - 25
