Cod unitate exterioara multisplit | U.M. | GWHD(28)NK6OO (LC)(LH) | |
Functie | Racire/Incalzire | ||
Capacitate | Racire | Btu/h | 28000 (7800 – 37500) |
Incalzire | Btu/h | 32400 (9600 – 35000) | |
SEER/SCOP | W/W | 7.20/4.20 | |
Alimentare | (Ph-V-Hz) | (1 Ph-220V-240V-50Hz) | |
Putere electrica | Racire/Incalzire | kw | 3.60/3.60 |
Curent electric | Racire/Incalzire | A | 15.97/15.97 |
Interval temperatura exterioara de functionare (Min-Max) | Racire | ºC | (-15, +43) |
Incalzire | ºC | ( -22, +24) | |
Dimensiune carcasa | LxlxH | mm | 9964x402x660 |
Dimensiune ambalaj | LxlxH | mm | 1032x456x737 |
Greutate neta/bruta | Kg | 51.0 / 55.5 | |
Nivel de presiune acustica | dB/A | 58.0 | |
Nivel de putere acustica | dB/A | 68.0 | |
Traseu frigorific | Diametru conducte lichid/gaz | mm | 4 x 6.35/4 x 9.52 |
Lungime maxima totala/unit. ext. – ultima unit. int. | m | 70/20 | |
Diferenta maxima nivel (unit. ext-unit. Int.) | m | 15 | |
Diferenta maxima nivel (unit int-unit. Int) | m | 15 | |
Numar maxim unitati interioare | buc | 4 | |
Refrigerant | R32 |
Capacitate ( Btu/h ): 28000
